Technical Specifications

• Jamming Frequency Bands: 400 MHz to 6.2 GHz
• Jamming Coverage Angles:
  • Vertical 30 deg / Horizontal 30 deg High Bands
  • Vertical 60 deg / Horizontal 60 deg Mid Bands
  • Vertical 90 deg / Horizontal 90 deg Low Bands
• Operating Temperature with external battery: -30°C to 60°C / -22°F to 140°F
• Overall Dimensions: 326mm (L) x 75mm (W) x 94mm (H) Radome
• Weight Including Internal Battery: 1370 g / 48.3 oz / 3.0 lbs
• Weight Including external HC PRC Battery: 1750 g / 61 oz / 3.8 lbs
• Power Supplies: Internal LiFePO4 Cells /Standard External Battery AN / PRC-148/152 STUB
  (Extended) External Tether BB-2590
• Standard Power Life STBY Mode:
  • With Internal Battery Only up to 3 hours
  • With External PRC Battery up to 8 hours
• IP Rating: IP66 / IP67
